Frontansicht des IDEAL Stapelschneider THE 68

Seitenansicht des IDEAL Stapelschneider THE 68

Guillotines

THE 68

Name: THE 68
Brand: de-ideal
SKU: 68801011
Price: 16059.0 EUR
Availability: InStock

€16.059,00

Prices valid in Germany incl. 19% VAT (Online sales in Germany only. For other countries, please contact your local dealer).

Equipment

Find a dealer

IDEAL THE 68, hydraulic guillotine with 680 mm cutting length, with IR light beam safety curtain and hydraulic clamping – Made in Germany.

highlights

Program-controlled stack cutter for maximum efficiency in professional applications.
Operation and program control via a 15.6" touchscreen for intuitive user guidance, just like on a tablet.
Hydraulic pressing with programmable pressing pressure for optimal results.
SCS safety concept: Integrated safety light curtain on the front table for maximum operator safety, safe two-hand cutting activation.
EASY-TOUCH two-hand cut-out trigger with illuminated status display
PRECISION-DRIVE for manual fine adjustment of the backstop
CUT-CONTROL: The current program with its respective program steps is displayed in the dedicated program editing window.
Quick program creation with favorites, search function and USB interface.
Cutting programs with up to 99 chain dimensions per step can be saved.
Robust all-metal construction with ergonomically adjustable working height.
Fast, safe maintenance thanks to a blade replacement device with a covered blade.
Durable, repairable, produced in a resource-efficient way – Made in Germany

Description

The IDEAL THE 68 is a programmable, state-of-the-art stack cutter – designed for the highest demands on efficiency, ease of operation, and precision. With a cutting length of 680 mm and a cutting height of up to 80 mm, this model is ideal for printing companies, bookbinders, and finishers with regularly high cutting volumes.

Operation is via a generous 15.6" multi-touch display, which clearly displays all functions and can be controlled via swipe and touch gestures. The integrated CUT-CONTROL software enables the quick creation and management of cutting programs - including a favorites function, search mode, and programmable pressing pressure. With the DATA-MANAGER, programs can be structured according to user, customer or project and saved on a supplied USB stick.

The core component is the PRECISION-DRIVE: an electromechanical blade drive in combination with hydraulic pressing. The pressing force can be adjusted steplessly and programmatically. The fine adjustment of the backstop is conveniently done via an ergonomic control element on the front of the machine. For manual interventions, a patented foot press is also available - independent of the machine drive.

The comprehensive SCS – Safety Cutting System protects the user with an electronically monitored IR light barrier on the front table, a closed back table, and a safe two-hand cutting release (EASY-TOUCH). The blade change is simple, safe, and tool-supported – with a covered cutting edge and animated assistance.

Thanks to its solid all-metal construction, an ergonomically adjustable working height (950–1000 mm) and durable components, the THE 68 is particularly robust and sustainable – with long-term spare parts supply and excellent repairability. A future-proof cutting system for professional use "Made in Germany".

specifications

Model: THE 68
Order number: 68801011
Dimension: 1523 x 1099 x 1331 mm (H x W x D), width with extension table 1899 mm
Weight: 330 kg, 343 kg with additional tables, 343 kg with cladding, 356 kg with cladding and additional tables
Cutting length: 680 mm
Cutting height: 80 mm, 77 mm with press beam cover
Restschnitt: 15 mm, 60 mm with press beam cover
Insertion depth: 680 mm
Table dimensions: 430 mm front table depth, 375 mm usable
Pressing: Automatic pressing
Press pressure: 250 – 1000 daN
Backgauge: electric
Side stop: behind, on the left and right
Knife drive: electric
Control: 15.6 inch touchscreen display
Connection values: 230 V / 50 Hz / 2.3 kW

Downloads

Betriebsanleitung

Shipping and Payment

Free Shipping:
for orders over €50.00

Shipping options:
by GLS parcel delivery for 5.95 €

Payment methods:
Visa, Mastercard, American Express, Maestro, UnionPay, Klarna, PayPal, Shop Pay, Apple Pay, Google Pay

Quality from Germany

Long-term repairable

Sustainable product

More details

Ein Druckerei-Mitarbeiter prüft einen Druckbogen neben einer großen Druckmaschine. Der Arbeitsbereich wirkt sauber, modern und minimalistisch. Im Hintergrund steht ein IDEAL THE 56 Stapelschneider mit Lichtschranke und großem Touch-Display.

Intelligent cutting solution with touch display and extended cutting length.

Detailansicht eines IDEAL Stapelschneiders THE 56 oder THE 68. Rechts im Bild zu sehen die ir-Sicherheits-Lichtschranke.

Safety and efficiency combined.

A standard light barrier in the work area ensures safe, efficient, and professional operation. This technology not only protects the operator, but also enables a smooth workflow.

Seitliche Frontansicht des elektrischen Stapelschneiders IDEAL THE 56 oder THE 68 - zu sehen ist ein Bedienpanel mit zwei Leuchttasten (den Zweihand-Schnittauslösetasten), eine Art Joystick und ein Teil der Lichtschranke.

Precision and safety in one package.

EASY-TOUCH – the two-hand cutting trigger for maximum comfort and safety. Intuitive push buttons with integrated, illuminated operating status display ensure simple and reliable operation.

Detailansicht eines IDEAL Stapelschneiders THE 56 oder THE 68. Zu sehen ist der optische LED-Schnittandeuter: Auf einer Metalloberfläche liegt ein weißer Papierstapel, darüber ist das Stapelschneider-Messer, auf dem Papierstapel verläuft eine rote Licht-Sichtlinie.

Precision that shines.

The optical cutting indicator with bright LEDs projects the exact cutting line onto the material, enabling precise cutting according to cutting marks. This function ensures maximum accuracy and efficiency with every cut.

Szenenbild aus dem Video zum programmierbaren Stapelschneider IDEAL THE56 mit Fokus auf das große 15,6"-Bedien-Display: Zwei Hände justieren den Winkel des auf der Maschinenoberseite angebrachten Displays für eine optimale Sicht.

Intuitive operation guaranteed.

The functional graphical user interface allows for intuitive control – as easy as on a tablet. The clear main screen with intelligent display ensures maximum user-friendliness. The swivelling display can be ergonomically adjusted to suit height and lighting conditions.

Nahaufnahme einer sicheren Messerwechsel-Szene bei einem IDEAL Stapelschneider THE 56 oder THE 68. Zwei Hände halten ein Werkzeug mit dem Stapelschneider-Messer.

Safe blade change made easy.

The clever blade changing device allows for a quick and safe change – without removing any housing parts. The covered cutting edge ensures maximum protection. This keeps blade changing simple, safe and efficient, so you can continue working without long interruptions!

Detailansicht auf das Bedienelement an der Maschinenfront des Stapelschneiders IDEAL THE 56 oder THE 68. Zu sehen ist eine Art „Joystick“, der die manuelle Feineinstellung des Rückanschlags ermöglicht.

Fine-tuning made easy.

The manual fine adjustment of the backstop ensures maximum precision – simple and convenient via the ergonomic control element on the front of the machine. The practical "joystick" allows for precise adjustment with minimal effort. Perfect cuts made easy – for precise and efficient work!

Save time, reduce costs.

Achieve the perfect cutting program in seconds: Speedcut, the optionally available automation program for THE 68, sets new standards. The innovative cutting mark recognition makes manual programming unnecessary – for maximum efficiency without time-consuming training. Optimized workflow, precise results, minimal effort.

Szenenbild aus dem Bedien-Video des programmierbaren Stapelschneiders IDEAL THE56 mit Zoom auf eine Hand, die den Anpressdruck in der komfortablen Bedienoberfläche des großen 15,6“-Touchmonitors justiert.

Full control. Exact results.

CUT-CONTROL is the core of precise and efficient cutting. The intuitive touchscreen display allows for the creation, management, and execution of cutting programs with complete transparency throughout all work steps. Numerous comfort functions ensure simple, error-free operation – perfect for printing companies, production facilities, and copy shops that demand the highest precision and efficiency.
